Tier 22 Rated Polymer Concrete HandholeConcast polymer concrete handhole units are a great precast option when you need a lightweight, non-ferrous access box with no bottom. The handholes include a textured polymer cover which comes standard with hex head bolts and flush lifting rings. If more security is required, both Penta Head and SureLock bolts are available for maximum protection. A recessed space is molded into each cover where an aluminum ID3 plate of your choosing can be attached. |
BOX ASSY PART NUMBER Includes Hex Head Bolts & Polymer Cover(s) |
NOM. BOX SIZE Width x Length |
OUTSIDE DIM'S Width x Length |
DEPTH Inches |
---|---|---|---|
PH22-17-30-18 | 17" X 30" | 18.75" X 31.75" | 18 in. |
PH22-17-30-24 | 17" X 30" | 18.75" X 31.75" | 24 in. |
PH22-24-36-24 | 24" X 36" | 25.75" X 37.75" | 24 in. |
PH22-30-48-36 | 30" X 48" | 31.75" X 49.75" | 36 in. |
REPLACEMENT COVER Part Number |
COVER WIDTH Inches |
COVER LENGTH Inches |
WEIGHT Pounds |
---|---|---|---|
17-30-PH22 | 16.88 | 29.88 | 68 |
24-36-PH22 | 23.88 | 35.88 | 117 |
30-24-FPH22 | 29.88 | 23.88 | 99 |
30-24-MPH22 | 29.88 | 23.88 | 100 |
